The BLUEQUIP 240V SS Multistage Submersible Pump is a compact, easy-to-install, and corrosion-resistant pump that is ideal for a variety of AdBlue applications.
The BLUEQUIP 240V SS Multistage Submersible Pump are made from high-quality AISI 316 stainless steel, which makes them corrosion-resistant and durable. They are also 100% factory tested to ensure quality and reliability.
Note: 240V Electric Transfer Pump Only
Key features of the BLUEQUIP 240V SS Multistage Submersible Pump:
- Customisable power supply cable length
- Plug and pump solution thanks to built in capacitor and motor protection for single phase
- Robust delivery manifold for a safe installation
- Constant pressure application in combination with a variable speed drive
- Noiseless operation for maximum comfort
- Maximum running time at zero delivery of 2 minutes for added safety
The high-performance BLUEQUIP 240V SS Multistage Submersible Pump delivers up to 12m3 /h and 100m max head with motor power up to 2,2 KW. The electric motor is cooled by pumped liquid, and an internal capacitor and built-in thermal protection means the pump does not require connection to a control panel for starting. The new delivery head is a unique component made of precision casting stainless steel to provide extreme resistance to corrosion and ensuring a robust pipe connection. Each pump is equipped with high-efficiency hydraulics and abrasion resistant impellers that will ensure stable performance over many years.
OPERATING CONDITIONS
| Liquid Temperature | -5 / +40 |
| Max. Particle Size | up to 2 mm |
| Max. Installation Depth | 17 (with 20m power cable length) |
| Maximum operating pressure | 10 Bar |
TECHNICAL DATA
| Motor standard voltage: | Single Phase, Three Phase |
| Thermal protection | Single phase version: built into the motor up to 1.1 kW, Three phase: to be provided into the starter panel by the Installer |
| Enclosure Class | Suitable for submerged installation |
| Float switch option: | Single phase version without level regulator |
Pressure relief valve recommended when installing the multistage pump (Code CA 160-125)
